Chapter 6: Operation
Using the System Configuration Menu
6-94 011-003-991 EN
Each parameter in the System Configuration menu is described below:
Language: allows you to select English, German, Spanish, Italian or French language text. NOTE: After selecting lan-
guage, press Enter, then GoBack/Esc.
Units: allows you to select USCS (English) or Metric units.
Password: allows you to set a password that limits access to the System Configuration Menu, weld setup or recalling a
preset.
Start Screen: allows you to choose whether to start at the Main menu or Run screen on power up.
Preset Counter: allows you to reset the running preset counter.
RS232: allows you to turn the Remote Terminal or Host Computer operation of the Power Supply on and off. Additionally,
weld data is sent out through the serial port after each weld as an ASCII string and can be read by either a PC or PLC.
Welder Address: identifies welder used for data collection. 4 digit numeric ID, from 1 to 9999.
Gen Alarm Reset: allows you to set whether a reset is required following a general alarm condition.
Time: allows you to set the current time, in HH:MM format, on a 24-hour clock.
Date: allows you to set the current date, in MM/DD/YY format.
Beepers: allows you to turn the Trigger Beeper, the Error Beeper, and the Alarm Beeper on and off. For Hand Held oper-
ation, Trigger Beeper is replaced by Release Beeper. The Release Beeper, if enabled, will sound with a single 500ms
pulse when the cycle start signal can be released.
P/S Settings: allows Power Supply selection, and configuration for the analog supply.
Amp Control: allows you to set whether amplitude is controlled internally (INT) or externally (EXT).
Extra Cooling: when On, allows cooling air to start when upper limit switch is triggered and remain on throughout cycle.
When Off, air is applied at ultrasonics application.
Act Settings: allows you to set the diameter (in inches or millimeters) of your cylinder, and the stroke length in inches or
millimeters.
Hand Held: is turned On or Off. Hand Held will run in Time, Energy, Ground Detect and Peak Power modes except for
control level “t”. “t” will only run Time and Ground Detect modes.
Ext Presets: is turned On or Off and can be used in both normal and Hand Held modes.
User I/O: allows you to define how configurable inputs/outputs are used.
Bar Graph Scales: allows you to set the weld scale and test scale to 1X, 2X, or 3X.
Digital Filter: allows you to turn the digital filter for graphing on or off.
Freq Offset: allows you to set whether the frequency offset is internally (INT) or externally (EXT) controlled.
