2000X energy Power Supply Chapter 6: Operation
Instruction Manual Using the System Configuration Menu
011-003-991 EN 6-119
User Definable I/O
This feature allows the user to select from a list of features, and assign the feature to their choice of input
or output pin on the I/O connector J3. The User Definable I/O’s can be disabled.
There are 8 available features for the 6 available J3 inputs . These features are described in the following
Table.
There are 11 available features for the 3 available J3 outputs. These are described in the following Table.
Table 6-1: Features for User I/O Inputs
Feature No. Feature Name Feature Description
1 Select Preset
Select up to 16 presets from 5 of the inputs (J3-1 input
does not have this feature)
2 Display Lock
When User I/O Input Display Lock is turned on, the front
panel display cannot access any means of changing the
current display.
3 External Signal
This input is used to enable Amplitude or Force step-
ping, and in Hand Held mode for starting sonics.
4 External U/S Delay
Delays starting of ultrasonics up to 30 seconds after trig-
ger conditions are met.
5 Sonics Disable
This is a form of Dry Cycle. It allows running a preset as
defined, but not turning on ultrasonics.
6 Memory Reset
Center power supply when input is active, used for
sequencing.
7 External Start
Allows power supply to close safety door, then start weld
cycle. Start signal would activate this External Start out-
put. When the External Start input becomes active then
the SV is activated. Must be used with External Start
input.
8 Sync In
Works in conjunction with Sync Out to Allow several
welders to work together and start sonics on all welders
at the same time after all have triggered.
Table 6-2: Features for User I/O Outputs
Feature No. Feature Name Feature Description
1 Amplitude Decay
Output indicates when amplitude has dropped below
defined value. Could be used to indicate when safe to
switch stacks.
2 External Beeper Echoes the same signal that goes to the internal beeper.
3Cycle OK
Means a complete cycle was run and there were no
alarms.
4 Confirm Preset An external preset change request has been honored.
5 No Cycle Alarm
Active when a No Cycle alarm occurs. It is cleared by
thre next cycle or a reset.
