2000X energy Power Supply Chapter 2: The 2000X energy Power Supply
Instruction Manual Glossary of Terms
011-003-991 EN 2-13
Recall Preset: Allows a user to recall a preset from memory for purposes of operation or modification.
Reject Limits: User-definable limits at which the violating cycle is identified as having produced a bad part.
Required: State used with limits indicating that a reset will be required when the limit is exceeded. The reset
is accomplished by using the reset key on the front of the Power Supply, or by external reset at the User I/O.
Reset Required: State used with alarms indicating that a reset will be required before a cycle can be run.
The reset is accomplished by using the reset key on the front of the Power Supply, or by external reset at
the User I/O.
Run Screen: The screen showing weld status, alarms, weld count, and process information.
Save Preset: Stores a programmed set of weld parameters as a preset.
Scrub Time: The amount of time after detection of a ground condition to the termination of ultrasonics.
Seek: A setting where ultrasonics are on at 5% amplitude for the purpose of finding the resonant frequency
of the stack.
Serial Port: A RS232 port provided to you for external data communications.
Stack: Converter, Booster, and Horn.
Step @ T (S): User-definable time at which Amp A or Force A is changed to AmpB or Force B.
Step @ E (J): User-definable energy at which AmpA/Force A is changed to AmpB/Force B.
Step @ Pwr (%): User definable power at which AmpA/Force A is changed to AmpB/Force B.
Step @ Col (in): User-definable collapse distance at which AmpA/Force A is changed to AmpB/Force B.
Step @ Ext Sig: Allows you to step either Force or Amplitude based upon an external signal.
Suspect Limits: User-defined limits which specify weld results used to identify a part as poten-
tially suspect, but not necessarily enough to reject the part.
Test Scale: The magnification of the power bar scale on the front panel while the Test key is pushed.
Time Mode: Terminates the ultrasonics at a user-specified time.
Timeout: A time at which the ultrasonic energy terminates if the main control parameter has not been
reached.
Trigger Beeper: An audible signal sounded when the trigger is made.
Upper limit switch (uls): A switch when activated indicates the actuator is in the home position.
UPS: Power Supply module; can be either analog (AUPS) or digital (DUPS).
User-defined limits for process resultants, where – is the user-defined lower limit, and + is the user defined
upper limit:
–/+ Energy: The energy reached during the weld.
–/+ Force: The force at the end of the weld.
–/+ Power: The peak power as a percentage of the maximum reached during the weld.
–/+ Time: The weld time reached during the weld.
-/+ Abs D: The absolute distance from the Home position reached during the weld.
–/+ Col D: The collapse distance reached during the weld.
–/+ Trg D: The position at which the trigger occurred.
Velocity Graph: A printed graph of the velocity of the actuator during descent.
Weld Count: Count of completed weld cycles.
