Chapter 2: The 2000X energy Power Supply
Glossary of Terms
2-14 011-003-991 EN
Weld Energy: The energy specified to be applied to the part during the weld cycle.
Weld Force: The force at the end of the weld cycle.
Weld History: The last 50 weld summary data lines that are saved and can be printed.
Weld Scale: The magnification of the power bar scale on the front panel during a weld cycle.
Weld State: A screen message showing the current state of the welder during or before the process. The
list of messages are shown in the Run Screen section.
Weld Summary Data: A one-line summary of information associated with the last weld cycle.
Weld Time: The time for which ultrasonics are on.
