Appendix B Terminal Settings
Terminal Setup
B-2 011-003-991 EN
Function Key Setup Parameters
The following parameters are set up from the Terminal’s Setup Mode.
5 Press F12 again to exit the terminal Setup mode.
F1: F1 Key Setup, DISP
Columns 80 Cursor Blink Blk Scrn Saver Off
Lines 25 Display Light Char Cell 10x15
Page 1 x Lines Autopage Off
80/132 Clr On
F2: F2 Key Setup, GENRL
Personality VT220-8 Enhance On Status Line Off
Scrl Jump
Autoscrl On Wrap EOL Off
Rcv CR CR Monitor Off
Recognize
DEL
Off
F3: F4 Key Setup, KEYBD
Keyclick On Repeat On Keycode ASCII
Keylock Caps Language US Corner Key Funct
F4: F4 Key Setup, COMM
Comm FDX Xmt Lim None
Answerback
Mode
Off
Mdm Rc Hsk None
Mdm Rc Hsk
Level
192
Mdm Xmt
Hsk
None
Aux Rc Hsk None Send ACK Off Aux Xmt Hsk None
F5: F5 Key Setup, PORTS
Mdm Baud
Rate
9600
Mdm Data/
Parity
8/None
Mdm Stop
Bits
1
Aux Baud
Rate
9600
Aux Data/
Parity
8/None Aux Stop Bits 1
Host Port Modem Port
Printer
Attached
On
Nulls
Suppress
On
