2000X energy Power Supply Chapter 4: Installation and Setup
Instruction Manual Start Switch Connection (Automation)
011-003-991 EN 4-31
The power supply can be permanently damaged if it is connected to the incorrect line voltage,
or if the wiring connection is mis-wired. It also presents a safety hazard if mis-wired. Use of
the correct plug or connector helps prevent incorrect connections.
Figure 4.13 International Harmonized Line Cord Color Code
BLUE = Neutral 120v operation, Line for 220
BROWN = Line
GREEN/Yellow trace = Earth Ground
Line Cord jacket
