Brother HL-S7000DN Service Manual

2-19
Confidential
7104 Paper jam. (While back cover is
closed, after paper eject sensor
shifted to paper feeding state,
even if a certain amount of
paper is fed, paper eject sensor
remains at paper feeding state.)
2-78
7105 ---
7106 Paper jam. (While back cover is
closed, after print starting
sensor shifted to no paper
state, switchback sensor
remains at paper feeding state.)
2-78
7200 ---
7201 Paper jam. (When performing
MP printing, while MP paper
empty sensor is at with paper
state, registration front sensor
does not change to paper
feeding state.)
2-79
7300 ---
7301 Paper jam. (When printing is
started by tray 1, even if a
certain amount of paper is fed,
paper feed sensor does not
change to paper feeding state.)
2-80
7302 Paper jam. (While paper feed
sensor is at paper feeding
state, even if a certain amount
of paper is fed, registration front
sensor does not change to
paper feeding state.)
2-81
7400 ---
7401 Paper jam. (When printing is
started by tray 2, even if a
certain amount of paper is fed,
T2 paper feed sensor does not
change to paper feeding state.)
2-81
7402 Paper jam. (While tray 2 paper
feed sensor is at paper feeding
state, even if a certain amount
of paper is fed, registration front
sensor does not change to
paper feeding state.)
2-82
Error
Codes
Problem
Refer
to:
7501 Paper jam. (When printing is
started by tray 3, even if a
certain amount of paper is fed,
T3 paper feed sensor does not
change to paper feeding state.)
2-82
7502 Paper jam. (While tray 3 paper
feed sensor is at paper feeding
state, even if a certain amount
of paper is fed, registration front
sensor does not change to
paper feeding state.)
2-83
7600 ---
7601 Paper jam. (When printing is
started by tray 4, even if a
certain amount of paper is fed,
T4 paper feed sensor does not
change to paper feeding state.)
2-83
7602 Paper jam. (While tray 4 paper
feed sensor is at paper feeding
state, even if a certain amount
of paper is fed, registration front
sensor does not change to
paper feeding state.)
2-84
7701 ---
7702 Paper jam. (After SWBK sensor
shifted from paper feeding to no
paper state, even if a certain
amount of paper is fed, 2-sided
jam sensor does not change to
no paper state.)
2-84
7703 ---
7704 Paper jam. (After 2-sided jam
sensor is shifted from paper
feeding status to paper-less
status, although a certain
amount of paper is fed, paper
feed sensor does not turn to the
paper feeding state.)
2-85
7705 Paper jam. (While 2-sided jam
sensor is at paper feeding
state, even if a certain amount
of paper is fed, paper feed
sensor does not change to no
paper state.)
2-85
7800 ---
Error
Codes
Problem
Refer
to:

Brother HL-S7000DN Specifications

General

Color	No
Duplex printing	Yes
Maximum duty cycle	275000 pages per month
Number of print cartridges	-
Page description languages	BR-Script 3, PCL 6, PostScript 3
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	100 ppm
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Plain paper, Recycled paper, Thin paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Multi-purpose tray media types	Bond paper, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Paper tray media weight (imperial)	16 - 28 lbs
Sound power level (standby)	40 dB
Sound power level (printing)	64 dB
Total input capacity	500 sheets
Maximum input capacity	1100 sheets
Maximum number of input trays	4
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, EAP-FAST, EAP-TLS, EAP-TTLS, LEAP, PEAP, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK, WPS
Mobile printing technologies	Brother iPrint & Scan
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.5 W
Power consumption (standby)	30 W
Power consumption (printing)	130 W
Operating temperature (T-T)	18 - 33 °C
Operating relative humidity (H-H)	20 - 80 %
Display	LCD
Product color	Black, White
Market positioning	Business
Package weight	52000 g
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	472 mm
Width	478 mm
Height	484 mm
