Brother HL-S7000DN Service Manual

2-20
Confidential
7801 Paper jam. (After switchback
sensor is at paper feeding
state, even if a certain amount
of paper is fed, optional output
sensor does not change to
paper feeding state.)
2-86
7802 Paper jam. (While optional
output sensor is at paper
feeding state, even if a certain
amount of paper is fed, optional
output sensor does not change
to no paper state.)
2-86
7A00 ---
7B00 ---
7C00 ---
7D00 ---
7E00 ---
7F00 ---
8000 ---
8100 ---
8200 ---
8300 ---
8400 ---
8501 When paper is fed from tray 1
or another tray located below
tray 1, paper width sensor
detected that tray 1 is open.
2-87
8502 When paper is fed from tray 2
or another tray located below
tray 2, paper width sensor
detected that tray 2 is open.
2-87
8503 When paper is fed from tray 3
or tray 4, paper width sensor
detected that tray 3 is open.
2-88
8504 When paper is fed from tray 4, it
was detected that tray 4 is
open.
2-88
Error
Codes
Problem
Refer
to:
8505 When paper feeding is
specified from tray 1 or the tray,
which is lower than the tray 1, it
was detected that the tray 1
was opened while printing.
2-89
8506 When paper feeding is
specified from tray 2 or the tray,
which is lower than the tray 2, it
was detected that the tray 2
was opened while printing.
2-89
8507 When paper feeding is
specified from tray 3 or tray 4, it
was detected that tray 3 was
opened while printing.
2-90
8508 When paper feeding is
specified from tray 4, it was
detected that tray 4 was
opened while printing.
2-90
8601 Although paper feeding from
tray ID 1 is specified, tray ID 1
is not set to any of the trays.
2-91
8602 Although paper feeding from
tray ID 2 is specified, tray ID 2
is not set to any of the trays.
2-91
8603 Although paper feeding from
tray ID 3 is specified, tray ID 3
is not set to any of the trays.
2-91
8604 Although paper feeding from
tray ID 4 is specified, tray ID 4
is not set to any of the trays.
2-91
8700 ---
8701 When auto is specified to eject
tray, it was detected that stack
sensor of all eject trays became
full state.
2-92
8702 When paper eject tray is
specified, the stack sensor of
paper eject tray detected full
state.
2-92
Error
Codes
Problem
Refer
to:

Brother HL-S7000DN Specifications

General

Color	No
Duplex printing	Yes
Maximum duty cycle	275000 pages per month
Number of print cartridges	-
Page description languages	BR-Script 3, PCL 6, PostScript 3
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	100 ppm
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Plain paper, Recycled paper, Thin paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Multi-purpose tray media types	Bond paper, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Paper tray media weight (imperial)	16 - 28 lbs
Sound power level (standby)	40 dB
Sound power level (printing)	64 dB
Total input capacity	500 sheets
Maximum input capacity	1100 sheets
Maximum number of input trays	4
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, EAP-FAST, EAP-TLS, EAP-TTLS, LEAP, PEAP, WPA-AES, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK, WPS
Mobile printing technologies	Brother iPrint & Scan
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.5 W
Power consumption (standby)	30 W
Power consumption (printing)	130 W
Operating temperature (T-T)	18 - 33 °C
Operating relative humidity (H-H)	20 - 80 %
Display	LCD
Product color	Black, White
Market positioning	Business
Package weight	52000 g
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	472 mm
Width	478 mm
Height	484 mm
