Cisco ASR 9000 Series Command Reference

VRF: vpn1 (0x60000002), IPv4 Table: default (0xe0000002), IPv6 Table: default
(0xe0000002)
IPv4: State: Up(9) (old: Adjacency added(8))
Last state change: May 11 16:33:08 (00:03:08 in current state)
IPv6: State: Up(9) (old: Adjacency added(8))
Last state change: May 11 16:33:08 (00:03:08 in current state)
RP/0/RSP0/CPU0:router# show ipsubscriber interface brief
Codes: INV - Invalid, INIT - Initialized, STRTD - Session Creation Started,
CPEXCTG - Control-Policy Executing, CPEXCTD - Control-Policy Executed,
FTAPPLD - Session Features Applied, VRFCFGD - VRF Configured,
ADJADDG - Adding Adjacency, ADJADDD - Adjacency Added, UP - Up,
DOWN - Down, DISCG - Disconnecting, DISCD - Disconnected, ERR - Error,
UNKWN - Unknown State, PKT - Packet Trigger Initiation,
PKTv6 - Packet Trigger Initiation for IPv6,
DHCP - DHCP Initiation, DHCPv6 - DHCPv6 Initiation
Interface Proto Subscriber IP MAC Address Sublabel VRF
State
---------------------- ------ ------------------ ------------------ ---------- ----------
----------
Gi0/0/0/0.ip1 DHCP 1.10.10.9 0100.0000.0000 0x40 default
UP
DHCPv6 0100.0000.0000 0x40 default
UP
Gi0/0/0/0.ip2 PKT 2.20.20.9 0200.0000.0000 0x20 default
UP
PKTv6 0200.0000.0000 0x20 default
UP
Gi0/0/0/0.ip3 DHCPv6 5.40.20.9 0200.2200.0000 0x21 default
UP
Gi0/0/0/0.ip4 PKTv6 7.91.20.9 0200.2210.0000 0x31 default
UP
This is the sample output of the show ipsubscriber interface outer-vlan-id command:
RP/0/RSP0/CPU0:router# show ipsubscriber interface outer-vlan-id 200 inner-vlan-id 100
Interface: Bundle-Ether1.200.ip1
Type: L2-connected
Access Interface: Bundle-Ether1.200
Subscriber MAC: 0000.0000.0014
Subscriber IPv4: 1.10.9.246
Subscriber Label: 0x4f
IPv4 Initiator: Packet-Trigger
VLAN ID: outer 200 inner 100
Created: Dec 22 00:32:28 (age 00:00:43)
VRF: default, IPv4 Table: default
IPv4 State: Up (old: Adjacency added)
Last state change: Apr 9 00:32:28 (00:00:43 in current state)
This is the sample output of the show ipsubscriber interface dynamic-routes command:
RP/0/RSP0/CPU0:router# show ipsubscriber interface dynamic-routes
Interface Dynamic-Routes
---------------------- ------------------------------------------------------------
BE1.1.ip3 45.1.32.0/24 (vrf vpn1) nhop 12.1.0.32 (vrf vpn1) distance 3 tag 34
(added)
BE1.1.ip4 45.1.33.0/24 (vrf vpn1) nhop 12.1.0.33 (vrf vpn1) distance 14 tag
340 (added)
This table describes the significant fields shown in the display.
Table 16: show ipsubscriber interface Field Descriptions
DescriptionField
Specifies the access interface type.Interface
Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release
5.2.x
291
IPoE Commands
show ipsubscriber interface
