Cisco ASR 9000 Series Command Reference

DescriptionField
IP Control Protocol (IPCP) state. The seven possible
states that may be displayed are as follows:
• Initial—Lower layer is unavailable (Down), and
no Open has occurred. The Restart timer is not
running in the Initial state.
• Starting—An administrative Open has been
initiated, but the lower layer is still unavailable
(Down). The Restart timer is not running in the
Starting state. When the lower layer becomes
available (Up), a Configure-Request is sent.
• Closed— IPCP is not currently trying to
negotiate.
• Stopped—A Terminate-Request has been sent
and the Restart timer is running, but a
Terminate-Ack has not yet been received.
• Closing—A Terminate-Request has been sent
and the Restart timer is running, but a
Terminate-Ack has not yet been received. Upon
reception of a Terminate-Ack, the Closed state
is entered. Upon the expiration of the Restart
timer, a new Terminate-Request is transmitted,
and the Restart timer is restarted. After the
Restart timer has expired Max-Terminate times,
the Closed state is entered.
• Stopping—A Terminate-Request has been sent
and the Restart timer is running, but a IPCP-Ack
has not yet been received. Req-Sent.
• ACKsent—IPCP has received a request and has
replied to it.
• ACKrcvd—IPCP has received a reply to a
request it sent.
• Open—IPCP is functioning properly.
IPCP
Keepalive setting and interval in seconds for echo
request packets.
Keepalive
Cisco ASR 9000 Series Aggregation Services Router Broadband Network Gateway Command Reference, Release
5.2.x
401
BNG PPP Commands
show ppp interfaces (BNG)
