CONSOLE AI | Configuration - Offline (Huddle) | 104
Changing Channel Properties - USB Tx (Huddle)
You can use channel properties to modify a USB Tx channel. You can make any of the following changes:
Feature Description
Gain Gain adjusts the input volume level for a USB input in increments of
0.5dB.
Mute Mute a channel.
To change the properties for a USB Tx channel:
1. In the Navigation panel, choose Channel Properties.
The Channel Properties screen appears:
2. Click USB Tx to open the channel list.
3. Select the channel you want to change.
The USB Tx Channel Properties block appears:
Mute
4. To mute this channel, click the Mute button (the button changes to red if the channel is muted).
Gain
5. You can change the gain in any of the following ways:
• Drag the slider
• Type a value in the text box
• Click the incrementer and decrementer arrows beside the text box to set the value
CONSOLE AI User Manual
