CONSOLE AI | Configuration - Offline (Huddle) | 66
Crosspoint Type Description
Crosspoint Connections between channels that don’t involve microphones or
processing blocks are simple crosspoints, shown as green.
Gated Connections between a microphone and any other channel can be
Gated or Non-Gated. If you choose Gated, the connection between
the two channels follows whatever gating rules are assigned to the
microphone.
Non-Gated Connections between a microphone and any other channel can
be Gated or Non-Gated. If you choose Non-Gated, the connection
between the two channels doesn’t follow any gating rules.
Pre-AEC Setting a Pre-AEC crosspoint in the Matrix bypasses the cross-pointed
input audio from the AEC (Acoustic Echo Cancellation) reference. This
is primarily used for sound reinforcement applications to prevent mic
input channel audio from being degraded by AEC artifacts.
Remove a Channel Route
12.To remove a channel route, hover the mouse pointer over an existing route until the pointer changes to
a pencil icon.
13.Click the route to select it.
14.Press the Delete key OR right-click the route and choose Delete > Routes from the context menu.
Assign References
15.For more information about assigning standard references, see Assigning Standard References
(Huddle).
View/Change Properties
16.To view or change the properties for a channel, channel group, or gating group from within FlowView,
double-click the icon OR right-click an icon and choose Show Properties from the context menu.
The Properties block for that item appears at the bottom of the FlowView screen.
You can make any changes you want in the Properties block. See the corresponding section below on
Huddle channel properties for more details.
Assigning Standard References (Huddle)
Using a CONVERGE Huddle, you can assign input channels to output channel standard references. The
Huddle cannot use custom references. For more information about references, see About References.
Note:
Unlike CP2 projects, standard references are already created for you when you create a Huddle
project.
To assign a standard reference:
1. If you are not already in FlowView, from the Navigation panel, choose FlowView
™
.
The FlowView screen appears:
