CONSOLE AI | Configuration - Offline (Huddle) | 99
Changing Channel Properties - BMA CTH Speaker (Huddle)
You can use channel properties to modify a BMA CTH Speaker channel.
You can make any of the following changes:
Feature Description
Mute Mute a channel.
Gain Gain adjusts the volume level for a processing block in increments of
0.5dB.
Polarity Reverses the polarity of a speaker channel.
EQ Filter Adjusts specific frequency bands within a +/-12db range.
Limiter Establishes a ceiling level for the output.
To change the properties for a BMA CTH Speaker channel:
1. In the Navigation panel, choose Channel Properties.
The Channel Properties screen appears:
2. Click BMA CTH Speaker to open the channel list.
3. Select the channel you want to change.
The BMA CTH Speaker Channel Properties block appears:
Filter
4. To enable and configure a filter, click the Filter button.
The Filters dialog box appears:
