CONSOLE AI | Configuration - Offline (Huddle) | 96
Option Description
Ratio Changes the rate of compression applied to the input signal as the
signal exceeds the threshold level. The range is1:1 to 1:20dB. The
default is 1:1.
Release Sets the time increment used to restore the signal to the input level
when the signal drops below the threshold. Therange is 100ms to 2
seconds, in 5ms increments. The default is 500ms.
Note:
The graph reflects the input/output decibel levels with the gain, ratio, and threshold settings you
select.
16.Click Close.
Mute
17.To mute this channel, click the Mute button (the button changes to red if the channel is muted).
Gain
18.You can change the gain in any of the following ways:
• Drag the slider
• Type a value in the text box
• Click the incrementer and decrementer arrows beside the text box to set the value
Changing Channel Properties - Output (Huddle)
You can use channel properties to modify an Output channel.
You can make any of the following changes:
Feature Description
Active (Group only) Lets you choose which member of the group to show or modify.
Auto Sync Automatically sync every channel in the group when you make changes
to one channel.
Sync All (Group only) Lets you synchronize all the members of the group to match the settings
of the active member.
Mute Mute a channel.
Gain Gain adjusts the volume level for an output in increments of 0.5dB.
Polarity Reverses the polarity of an output channel.
EQ Filter Adjusts specific frequency bands within a +/-12db range.
Limiter Establishes a ceiling level for the channelFader output.
To change the properties for an Output channel:
1. In the Navigation panel, choose Channel Properties.
The Channel Properties screen appears:
