CONSOLE AI | Managing Channels (CP2) | 269
Changing Channel Properties - USB Tx and xUSB Tx (CP2)
You can use channel properties to modify a USB Tx or xUSB Tx (a USB transmit channel from a USB
Expander) channel. You can make any of the following changes:
Feature Description
Gain Gain adjusts the output volume level for a USB channel in increments of
0.5dB.
Mute Mute a channel.
To change the properties for a USB Transmit channel:
1. From the Navigation Panel, choose Channel Properties.
The Channel Properties screen appears.
2. (Optional) If you’re using Advanced Room mode, choose a partition from the Partition drop-down list.
3. (Optional) Choose a preset from the Preset drop-down list.
4. Click USB Transmit to open the channel list.
5. Select the channel you want to change.
The USB Transmit Channel Properties block appears:
Mute
6. To mute this channel, click the Mute button (the button changes to red if the channel is muted).
Gain
7. You can change the gain in any of the following ways:
• Drag the slider
• Type a value in the text box
• Click the incrementer and decrementer arrows beside the text box to set the value
Changing Channel Properties - Telco Tx (CP2)
You can use channel properties to modify a Telco Tx (analog phone line transmit) channel. You can make
any of the following changes:
Feature Description
Pre-Gain Adjusts the gain prior to any other channel modifications.
Mute Mute a channel.
Gain Gain adjusts the input volume level for a USB input in increments of
0.5dB.
To change the properties for a Telco Tx channel:
CONSOLE AI User Manual
