CONSOLE AI | Configuration - Offline (Huddle) | 78
Feature Description
Gain Gain adjusts the input volume level for a mic input but in increments of
0.5dB.
Acoustic Echo Cancellation
(AEC)
AEC (Acoustic Echo Cancellation) reduces or removes acoustical echo
from an input signal, thereby improving audio clarity. CONVERGE Pro
2 devices perform AEC using the full bandwidth (20Hz to 22kHz) of
the signal. AEC uses a reference source to perform AEC based on the
acoustic characteristics and dynamics of a specific room.
Noise Cancellation (NC) Noise Cancellation is a process in which ambient (background) noise is
removed from an input signal, with no noticeable degradation in signal
quality. This settings is used primarily for audio and video conferencing.
Mute Mute a microphone.
Filter Filters enable you to shape the audio signals from mic inputs channels
for improved audio quality. Up to four filters can be added to a mic input
channel. Available filter types are All Pass, High Pass, Low Pass, Notch,
and Parametric Equalizer (PEQ).
Automatic Level Control (ALC) ALC automatically keeps an input signal at a constant level, and is
generally used to keep speech levels constant onMic Input channels.
Automatic Gain Control (AGC) AGC keeps an input signal at a target gain level that you select, and is
generally used for Line Input channels.
Gate Settings Gate settings control when a microphone is gated on or off, based on
audio environment factors for this microphone and other microphones in
the same gating group.
To change the properties for a Mic/Line Input AEC channel:
1. In the Navigation panel, choose Channel Properties.
The Channel Properties screen appears:
2. Click Mic/Line Input AEC to open the channel list.
3. Select the channel you want to change.
The Mic/Line Input AEC Channel Properties block appears:
