Menu 11
Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance
Feature look-
up table
188 Unidrive SP Advanced User Guide
www.controltechniques.com Issue Number: 7
Indicates the type/mode of the data block selected with Pr 11.37 as shown in the following table.
Indicates the version number of the data block. This is intended to be used when data blocks are used as drive macros. If a version number is to be
stored with a data block this parameter should be set to the required version number before the data is transferred. Each time Pr 11.37 is changed by
the user the drive puts the version number of the currently viewed data block in this parameter.
Gives the checksum of the data block or the bytes left on the card if Pr 11.37 = 1000.
Sets the timeout for the drive display to revert to status mode from edit mode following no key presses. Although this parameter can be set to less
than 2s, the minimum timeout is 2s.
11.38 SMARTCARD data type/mode
Drive modes Open-loop, Closed-loop, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11111
Range Open-loop, Closed-loop, Servo, Regen 0 to 18
Update rate Background write
Pr 11.38 String Type/mode Data stored
0 FrEE Value when Pr 11.37 = 0
2 3OpEn.LP Open-loop mode parameters Data from EEPROM
3 3CL.VECt Closed-loop vector mode parameters Data from EEPROM
4 3SErVO Servo mode parameters Data from EEPROM
5 3rEgEn Regen mode parameters Data from EEPROM
6 to 8 3Un Unused
10 4OpEn.LP Open-loop mode parameters Defaults last loaded and differences
11 4CL.VECt Closed-loop vector mode parameters Defaults last loaded and differences
12 4SErVO Servo mode parameters Defaults last loaded and differences
13 4rEgEn Regen mode parameters Defaults last loaded and differences
14 to 16 4Un Unused
17 LAddEr Drive Onboard PLC program Drive Onboard PLC program
18 Option
A file containing user defined data
(normally created by an SM-Applications
option module)
User defined
11.39 SMARTCARD data version
Drive modes Open-loop, Closed-loop, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range Open-loop, Closed-loop, Servo, Regen 0 to 9,999
Default Open-loop, Closed-loop, Servo, Regen 0
Update rate Background read/write
11.40 SMARTCARD data checksum
Drive modes Open-loop, Closed-loop, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111 1
Range Open-loop, Closed-loop, Servo, Regen 0 to 65,335
Update rate Background write
11.41 Status mode time-out
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range
Open-loop, Closed-loop vector, Servo,
Regen
0 to 250 s
Default
Open-loop, Closed-loop vector, Servo,
Regen
240
Update rate Background read
