Access Point Profile QoS Commands 183
4 Wireless Commands
Access Point Profile QoS Commands
The commands in this section provide QoS configuration per radio interface and QoS queue
within an access point profile.
qos ap-edca
This command configures the downstream traffic flowing from the access point to the client
station EDCA queues – voice (0), video (1), best-effort (2), and background (3) queues. The
command allows you to configure AIFS (Arbitration Inter-Frame Spacing), Minimum
Contention Window, Maximum Contention Window, and Maximum Burst Duration for each
of these queues.
Default Voice
AIFS, 1 msec
Minimum Contention Window, 3 msecs
Maximum Contention Window, 7 msecs
Maximum Burst Duration, 1500 usec
Video
AIFS, 1 msec
Minimum Contention Window, 7 msecs
Maximum Contention Window, 15 msecs
Maximum Burst Duration, 3000 usec
Best-Effort
AIFS, 3 msec
Minimum Contention Window, 15 msecs
Maximum Contention Window, 63 msecs
Maximum Burst Duration, 0 usec
Background
AIFS, 7 msec
Minimum Contention Window, 15 msecs
Maximum Contention Window, 1023 msecs
Maximum Burst Duration, 0 usec
Format
qos ap-edca {background | best-effort | video | voice} {aifs
<1-255> | cwmin <cwmin-time> | cwmax <cwmax-time> | max-burst-
duration <0-999900>}
Mode AP Profile Radio Config
1-255 Arbitration Inter-Frame Spacing duration value in milliseconds
cwmin-time Minimum contention window value in milliseconds
cwmax-time Maximum contention window value in milliseconds
0-999900 Maximum burst length value in microseconds
