Figure 3 - 51 MLD Snooping Settings window
The following parameters may be viewed or modified:
Parameter Description
MLD Snooping
State
Click the redio button to enable or disable the MLD snooping function for the chosen VLAN.
Max Learned Entry
Value (1-1024)
Enter a number for the maximum value of MLD Snooping data driven learning.
To configure the settings for an existing entry click the corresponding Edit button which will display the following
window.
Figure 3 - 52 MLD Snooping Settings – Edit window
The following parameters may be viewed or modified:
Parameter Description
VLAN ID
This is the VLAN ID that, along with the VLAN Name, identifies the VLAN for which the user
wishes to modify the MLD Snooping Settings.
VLAN Name
This is the VLAN Name that, along with the VLAN ID, identifies the VLAN for which the user
wishes to modify the MLD Snooping Settings.
Rate Limit
Displays the rate limitation.
Querier IP
The querier IP address to send MLD queries.
Querier Expiry
Time
Displays the querier expiry time.
