sFlow Analyzer Server Settings
This window is used to configure the sFlow analyzer server settings. You can specify more than one analyzer server
with the same IP address but with different UDP port numbers. You can have up to four unique combinations of IP
address and UDP port numbers.
To view this window, click Configuration > sFlow > sFlow Analyzer Server Settings as shown below:
Figure 2 - 46 sFlow Analyzer Server Settings window
The following parameters can be configured:
Parameter Description
Analyzer Server I D ( 1-
4)
Up to four
sFlow Analyzer Servers can be configured.
Owner Name
The description about the sFlow analyzer server(s). When owner is set or modified, the
timeout value will become 400 automatically.
Timeout (1-2000000)
The length of time before the server is timed out. When the analyzer server times out, all
of the flow samplers and counter pollers associated with this analyzer server will be
deleted. “Infinite” indicates that the analyzer server will never time out. If not specified, the
default value is 400.
Collector Address
The IP address of the analyzer server. If not specified, the address will be 0.0.0.0 which
means that the entry will be inactive.
Collector Port (1 -
65535)
The destination UDP port for sending the sFlow datagrams. If not specified, the default
value is 6343.
(300-1400)
The maximum number of data bytes that can be packed in a single sample datagram. If not
specified, the default value is 1400.
Click Apply to implement the changes made.
sFlow Flow Sampler Settings
This table is used to create sFlow flow sampler settings on the Switch. By configuring the sampling function for a port,
a sample packet received by this port will be encapsulated and forwarded to the analyzer server at the specified
interval.
To view this window, click Configuration > sFlow > sFlow Flow Sampler Settings as shown below:
