LLDP Dot1 TLVs Settings
LLDP Dot1 TLVs are organizationally specific TLVs which are defined in IEEE 802.1 and used to configure an
individual port or group of ports to exclude one or more of the IEEE 802.1 organizational port vlan ID TLV data types
from outbound LLDP advertisements.
To view this window, click L2 Features > LLDP > LLDP Dot1 TLVs Settings:
Figure 3 - 74 LLDP Dot1 TLVs Settings window
The following parameters can be set:
Parameter Description
From Port/To
Port
Use the pull-down menu to select a range of ports to be configured.
PVID
Use the drop-down menu to enable or disable the advertise PVID.
Protocol VLAN ID
Use the drop-down menu to enable or disable the advertise Protocol VLAN ID.
VLAN Name
Use the drop-down menu to enable or disable the advertise VLAN Name.
Protocol Identity
Use the drop-down menu to enable or disable the advertise Protocol Identity.
Click Apply to implement changes made.
