DHCP Server Manual Binding
The following windows will allow users to view and set manual DHCP entries. Manual DHCP entries will bind an IP
address with the MAC address of a device within a DHCP pool. These entries are necessary for special devices on
the local network that will always require a static IP address that cannot be changed. To view this window, click L3
Features > DHCP Server > DHCP Server Manual Binding:
Figure 4 - 14 DHCP Server Manual Binding window
The following parameters may be configured.
Parameter Description
Pool Name
Enter the name of the DHCP pool within which will be created a manual DHCP binding entry.
IP Address
Enter the IP address to be statically bound to a device within the local network that will be specified
by entering the Hardware Address in the following field.
Hardware
Address
Enter the MAC address of the device to be statically bound to the IP address entered in the
previous field.
Type
This field is used to specify the type of connection for which this manually bound entry will be set.
Ethernet will denote that the manually bound device is connected directly to the Switch, while the
IEEE802 denotes that the manually bound device is outside the local network of the Switch.
Click Apply to set the entry.
