MLD Snooping Static Group Settings
This window is used to configure the MLD Snooping static group information on the Swtich:
To view this window, click L2 Features > MLD Snooping > MLD Snooping Static Group Settings, as shown below:
Figure 3 - 55 MLD Snooping Static Group Settings window
The following parameters may be viewed or modified:
Parameter Description
VLAN Name
Specifies the name of the VLAN for which to configure the MLD snooping static group
information.
VLAN ID List (e.g.:1-3,5)
Specifies the list of the VLAN IDs for which to configure the MLD snooping static group
information.
IPv6 Address
Specifies the static group IPv6 address for which to configure the MLD snooping static
group information.
Click Create to create a new entry. To search for an entry enter the information and click Find. To view all previously
configured entries click View All.
MLD Multicast Group Profile Settings
This table allows the user to create MLD multicast group profiles and specify multicast address lists on the Switch.
To view this window, click L2 Features > MLD Snooping > MLD Multicast Group Profile Settings as shown below:
Figure 3 - 56 MLD Multicast Group Profile Settings window
To configure the group list once a profile has been created, click on the hyperlinked
Group List to reveal the following
window:
Figure 3 - 57 Multicast Group Profile Multicast Address Settings window – Group List
Enter the Multicast Address List and click Add the new information will be displayed in the table. Click <<Back to
return to the MLD Multicast Group Profile Settings window and click Delete to remove an entry.
