Area 3
Presents switch information based on your selection and the entry of configuration data.
NOTICE: Any changes made to the Switch configuration during the current
session must be saved in the Save Changes web menu (explained below)
or use the command line interface (CLI) command save.
Web Pages
When you connect to the management mode of the Switch with a web browser, a login window is displayed. Enter a
user name and password to access the Switch's management mode.
Below is a list and description of the main folders available in the web interface:
Configuration – A detailed discussion about configuring some of the basic functions of the Switch, including
accessing the System Information, Serial Port Settings, IP Address, Port Configuration, Static ARP Settings, User
Accounts, System Log Configuration, System Severity Settings, DHCP Relay, DHCP Local Relay Settings, DHCP
Auto Configuration Settings, MAC Address Aging Time, Web Settings, Telnet Settings, Password Encryption,
Clipaging Settings, Firmware Information, Dual Configuration Settings, PPPoE Circuit ID Insertion Settings, Ping
Test, SNTP Settings, MAC Notification Settings, PoE, SNMP Settings, sFlow, Stacking Mode Settings, Time Range
Settings, and Single IP Management.
L2 F eatures – A discussion of the Layer 2 features on the Switch, including Jumbo Frame, 802.1Q VLAN, Voice
VLAN, Subenet VLAN, QinQ, 802.1v Protocol VLAN, RSPAN Settings, GVRP Settings, GVRP Timer Settings,
Asymmetric VLAN Settings, MAC-based VLAN Settings, PVID Auto Assign Settings, VLAN Trunk Settings, Port
Trunking, LACP Port Settings, Traffic Segmentation, IGMP Snooping, MLD Snooping, Port Mirror, Loopback
Detection Settings, BPDU Attack Protection Settings, Spanning Tree, Forwarding & Filtering, LLDP, CFM, and
Ethernet OAM.
L3 F eatures – A discussion of the Layer 3 features on the Switch, including Ipv4 Interface Settings, Ipv4 Default
Route Settings, Gratuitous ARP, ARP Spoofing Prevention Settings, DNS Relay, DHCP Server and Policy Route
Settings.
QoS – Features information on Switch QoS functions, including HOL Blocking Prevention, Bandwidth Control,
Traffic Control, 802.1p Default Priority, 802.1p User Priority, QoS Scheduling Mechanism, QoS Scheduling, CoS
Bandwidth Control Settings and SRED.
Security – Features information on Switch security functions, including Safeguard Engine, Trusted Host, IP-MAC-
Port Binding, Port Security, DHCP Server Screening, 802.1X, SSL Settings, SSH, Access Authentication Control,
MAC-based Access Control, Web Authentication, JWAC, NetBIOS Filtering Settings, and Multiple Authentication.
ACL – Discussion on the ACL functions of the Switch, including ACL Configuration Wizard, Access Profile List, CPU
Access Profile List, ACL Finder, and ACL Flow Meter.
Monitoring – Features information about the monitoring functions on the Switch including, Device Status, Cable
Diagnostics, CPU Utilization, Port Utilization, Packet Size, Packets, Errors, Port Access Control, Browse ARP Table,
Browse Route Table, Browse VLAN, Show VLAN Ports, Browse Voice VLAN Device, Browse DHCP Server
Dynamic Binding, Browse DHCP Conflict IP, Browse Session Table, MLD Snooping, IGMP Snooping, Ethernet
OAM, JWAC Authentication State, MBA Authentication State, WAC Authentication State, ARP & FDB Table, MAC
Address Table, and System Log.
NOTE: Be sure to configure the user name and password in the User
Accounts window before connecting the Switch to the greater network.
