CFM Linktrace Settings
This window is used to configure the CFM linktrace settings on the Switch.
To view this window, click L2 Features > CFM > CFM Linktrace Settings as shown below:
Figure 3 - 88 CFM Linktrace Settings window
The following parameters can be configured:
Parameter Description
MEP Name
The name of the Maintenance End Point.
MEP ID (1-8191) The ID for the Maintenance End Point between 1 and 8191.
MD Name
The Maintenance Domain Name.
MA Name
The Maintenance Association Name.
MAC Address
The destination MAC address.
TTL (2-255) The linktrace message TTL value. The default value is 64.
PDU Priority
The 802.1p priority to be set in the transmitted LTM. If the PDU Priority is not specified, it uses
the same priority as CCMs sent by the MA.
Click Apply to implement changes made.
