DHCP Relay Option 60 Settings
This window is used to configure option 60 relay rules on the Switch. Different strings can be specified for the same
relay server, and the same string can be specified with multiple relay servers. The system will relay the packet to all
the matching servers.
To view this window, click Configuration > DHCP Relay > DHCP Relay Option 60 Settings as shown below:
Figure 2 - 17 DHCP Relay Option 60 Settings window
The following parameters may be configured.
Parameter Description
String
Enter the specified string, up to a maximum of 255 alphanumeric characters.
Server IP
Enter the relay server IP address.
Match Type Use the drop down menu to select either Exact Match or Partial Match.
Exact Match – The option 60 string in the packet must fully match the specified string.
Partial Match – The option 60 string in the packet only needs to partially match the specified
string.
Click Add to add a new entry. To search for a particular entry enter the correct IP Address or String and click Find. To
delete an entry select it and click Delete.
