MAC Address Table
This allows the Switch's dynamic MAC address forwarding table to be viewed. When the Switch learns an association
between a MAC address and a port number, it makes an entry into its forwarding table. These entries are then used to
forward packets through the Switch.
To view the MAC Address Table window, click Monitoring > MAC Address Table
Figure 8 - 45 MAC Address Table window
The functions used in the MAC address table are described below:
Parameter Description
Port
The port to which the MAC address below corresponds.
VLAN Name
Enter a VLAN Name for the forwarding table to be browsed by.
MAC Address
Enter a MAC address for the forwarding table to be browsed by.
Find
Allows the user to move to a sector of the database corresponding to a user defined port, VLAN,
or MAC address.
Clear Dynamic
Entries
Click this button will allow the user to delete all dynamic entries of the address table.
View All Entry
Click this button will allow the user to view all entries of the address table.
Clear All Entry
Click this button will allow the user to delete all entries of the address table.
Add to Static
MAC Table
Find an entry, and click the corresponding button to add the entry to the static MAC table.
