Connectivity Fault Management Settings
This window is used to configure the CFM settings on the Switch.
To view this window, click L2 Features > CFM > Connectivity Fault Management Settings as shown below:
Figure 3 - 86 Connectivity Fault Management Settings window
The following parameters can be set or are displayed:
Parameter Description
CFM State Used to Enable or Disable the CFM State.
Connectivity Fault Management Create(MD)
MD
Enter the maintenance domain name you wish to create.
Level
Enter the maintenance domain level.
Connectivity Fault Management Settings(MD)
MD
Enter the maintenance domain name you wish to configure.
MIP
This setting controls the creation of MIPs.
None – Means that no MIPs will be created. This is the default value.
Auto – MIPs are created when the next lower active MD-level on the port is reached or there are
no lower active MD levels.
Explicit – MIPs are created when the next lower active MD-level on the port is reached.
SenderID TLV
Used to define the TLV data types of the maintenance domain. The user can choose between
None, Chassis, Manage or Chassis Manage.
To create a new entry enter the appropriate information and click Add. To configure the settings enter the appropriate
information and click Apply.
