DHCP Packet
By default, the DHCP packet with broadcast DA will be flooded. When set to disable, the
broadcast DHCP packet received by the specified port will not be forwarded.
Mode
The user may set the mode for this IP-MAC binding settings by choosing one of the following:
ARP − This mode is specified as an arp mode. This will not be added as access entries. If the
system is in ARP mode, both ARP mode and ACL mode will be effective.
ACL − This mode is specified as an ACL mode. If user enable ACL mode, this mode will be
added as access entry.
SLT (0-500) Enter the number, 0-500, for Stop-learning Threshold. The default SLT for each port is 500.
Max Entry (1-50)
Specifies the maximum number of IP-MAC-Port Binding entries. By default, The maximum
entry for each port is No Limit.
IMP Binding Entry Settings
This table is used to create Static IP MAC Binding Port entries on the switch.
To view this window click, Security > IP-MAC-Port Binding > IMP Binding Entry Settings
Figure 6 - 6 IMP Binding Entry Settings window
The following fields can be set or modified:
Parameter Description
IP Address
Enter the IP address to bind to the MAC address set below.
MAC Address
Enter the MAC address to bind to the IP Address set above.
Ports
Specify the switch ports for which to configure this IP-MAC binding entry (IP Address + MAC
Address). Click the All Ports check box to configure this entry for all ports on the Switch.
Click Apply for implement changes, click Find to search for an entry, click Show All for the table to display all entries
and click Delete to remove an entry.
