ARP & FDB Table
This window displays current ARP & FDP entries on the Switch. To search a specific ARP or FDB entry, select a port
from the pull down menu, or enter a(n) MAC/IP Address at the top of the window.
The view this window, click Monitoring > ARP & FDB Table as shown below:
Figure 8 - 44 ARP & FDB Table window
The following fields can be configured or viewed:
Parameter Description
Port
The port to which the MAC address below corresponds.
MAC Address
Enter a MAC address for the forwarding table to be browsed by.
IP Address
Enter an IP address for the forwarding table to be browsed by.
Find By Port
Click this button to move to a sector of the database corresponding to a user defined port.
Find By MAC
Click this button to move to a sector of the database corresponding to a user defined MAC
address.
Find By IP
Address
Click this button to move to a sector of the database corresponding to a user defined IP address.
View All Entry
Click this button will allow the user to view all entries of the address table.
Add to IP MAC
Port Binding
Table
Find an entry, and click the corresponding button to add the entry to the IP-MAC-port Binding
table.
