D-Link xStack Reference Guide

xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide
1001
86-11 create vlan_translation_profile
Description
This command is used to create a flow-based VLAN translation profile. Multiple flow-based VLAN
translation rules can be specified for a profile.
Format
create vlan_translation_profile <profile_id>
Parameters
<profile_id> - Specifies the profile ID for the profile.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To create a VLAN translation profile:
DGS-3620-28SC:admin#create vlan_translation_profile 2
Command: create vlan_translation_profile 2
Success.
DGS-3620-28SC:admin#
86-12 config vlan_translation_profile
Description
This command is used to create a flow-based QinQ translation rule of a profile.
Format
config vlan_translation_profile <profile_id> add rule_id {<rule_id>} [add svid <vlanid 1-
4094> {priority <priority 0-7>} classify {source_mac <macaddr> {sa_mask <macmask>} |
destination_mac <macaddr> {da_mask <macmask>} | source_ipv4 <ipaddr> {sip_mask
<netmask>} | destination_ipv4 <ipaddr> {dip_mask <netmask>} | outer_vid <vidlist> | 802.1p
<priority 0-7> | ip_protocol <value 0-255> | l4_src_port <value 1-65535> | l4_dest_port
<value 1-65535>} | replace svid <vlanid 1-4094> {priority <priority 0-7>} classify outer_vid
<vlanid 1-4094> {source_mac <macaddr> {sa_mask <macmask>} | destination_mac
<macaddr> {da_mask <macmask>} | source_ipv4 <ipaddr> {sip_mask <netmask>} |
destination_ipv4 <ipaddr> {dip_mask <netmask>} | 802.1p <priority 0-7> | ip_protocol
<value 0-255> | l4_src_port <value 1-65535> | l4_dest_port <value 1-65535>}]
