D-Link xStack Reference Guide

xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide
271
Format
config cfm lm [mepname <string 32> | mepid <int 1-8191> md [<string 22> | md_index <uint
1-4294967295>] ma [<string 22> | ma_index <uint 1-4294967295>]] state [enable | disable]
Parameters
mepname - Specifies the MEP name.
<string 32> - Enter the MEP name. This name can be up to 32 characters long.
mepid - Specifies the MEP ID.
<int 1-8191> - Enter the MEP ID. This value must be between 1 and 8191.
md - Specifies the Maintenance Domain name.
<string 22> - Enter the Maintenance Domain name. This name can be up to 22 characters
long.
md_index - Specifies the Maintenance Domain index.
<uint 1-4294967295> - Enter the Maintenance Domain index. This value must be between 1
and 4294967295.
ma - Specifies the Maintenance Association name.
<string 22> - Enter the Maintenance Association name. This name can be up to 22
characters long.
ma_index - Specifies the Maintenance Association index.
<uint 1-4294967295> - Enter the Maintenance Association index.
state - Specifies the administrative state of frame loss measurement function on the MEP.
enable - Specifies that the frame loss measurement function will be enabled.
disable - Specifies that the frame loss measurement function will be disabled.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command. (EI Mode Only
Command)
Example
To configure the administrative state of frame loss measurement function as enabled:
DGS-3620-28SC:admin#config cfm lm mepname mep1 state enable
Command: config cfm lm mepname mep1 state enable
Success.
DGS-3620-28SC:admin#
16-37 show cfm dm
Description
This command is used to show the frame delay measurement information.
Format
show cfm dm [mepname <string 32> | mepid <int 1-8191> md [<string 22> | md_index <uint
1-4294967295>] ma [<string 22> | ma_index <uint 1-4294967295>]]
