xStack® DGS-3620 Series Layer 3 Managed Stackable Gigabit Switch CLI Reference Guide
670
<name 32> - The profile name can be up to 32 characters long.
access - (Optional) Specify whether the access is permit or deny.
permit - Specifies that the packets that match the addresses defined in the profiles will be
permitted.
deny - Specifies that the packets that match the addresses defined in the profiles will be
denied.
Restrictions
Only Administrator, Operator and Power-User level users can issue this command.
Example
To add multicast address profile 2 to ports 1 and 3:
DGS-3620-28SC:admin#config limited_multicast_addr ports 1,3 add profile_id 2
Command: config limited_multicast_addr ports 1,3 add profile_id 2
Success.
DGS-3620-28SC:admin#
55-7 show limited_multicast_addr
Description
This command is used to display a multicast address range by ports or by VLANs. When the
function is configured on a port or VLAN, it limits the multicast group operated by the IGMP/MLD
snooping function and layer 3 function. If the IPv4 or IPv6 option is not specified, IPv4 is implied.
Format
show limited_multicast_addr [ ports <portlist> | vlanid <vlanid_list>] {[ipv4 | ipv6]}
Parameters
ports - Specifies a range of ports to show the limited multicast address configuration.
<portlist> - Enter a range of ports to be displayed.
vlanid - Specifies the VLAN ID of VLANs that require information displaying about the multicast
address filtering function.
<vlanid_list> - Enter the VLAN ID of the VLAN here.
ipv4 - (Optional) Specify to display the IPv4 multicast profile associated with the port or VLAN.
ipv6 - (Optional) Specify to display the IPv6 multicast profile associated with the port or VLAN.
Restrictions
None.
Example
To display the limited multicast address range on VLAN 1:
DGS-3620-28SC:admin#show limited_multicast_addr vlanid 1
Command: show limited_multicast_addr vlanid 1
