Daewoo Mega 500-V - Page 103

S0502020K
Page 5
Center Joint (Articulation Joint)
Unit: mm
No. Check item Criteria Remedy
1
Clearance between lower
hinge pin and rear frame.
Standard
size
Tolerance Standard
clearance
Clearance
limit
Replace
100 -0.030
-0.076
+0.071
+0.036
0.030 -
0.130
-
2 Clearance between lower
hinge pin and spacer
(small).
100 -0.030
-0.076
+0.060
+0.030
0.060 -
0.136
-
3 Clearance between lower
hinge pin and bearing.
100 -0.030
-0.076
0
-0.015
0.015 -
0.076
-
4 Clearance between lower
hinge pin and spacer
(large).
100 -0.030
-0.076
+0.060
+0.030
0.060 -
0.136
-
5 Clearance between rear
frame and spacer (large).
115 -0.036
-0.090
+0.071
+0.036
0.072 -
0.161
-
6 Clearance between front
frame and upper hinge
bearing.
180 0
-0.025
-0.048
-0.088
-0.023 -
-0.088
-
7 Clearance between upper
hinge pin and rear frame.
100 -0.030
-0.076
+0.054
0
0.030 -
0.130
-
8 Clearance between upper
hinge pin and bearing.
100 -0.030
-0.076
0
-0.015
0.015 -
0.076
-
9 Clearance between front
frame and upper hinge
bearing.
180 0
-0.025
-0.048
-0.088
-0.023 -
-0.088
-
11 Height of lower hinge
spacer (small).
42 - - 0 0
12 Height of lower hinge
spacer (large).
81.5 - - 0 0
13 Shim thickness for lower
hinge and retainer (front
frame).
0.8 - 1.14 - - - -
14 Shim thickness for lower
hinge and retainer (rear
frame).
2.99 - 3.5 - - - -
15
Tightening torque of upper
hinge retainer mounting
bolt.
When adjusting with shim: 8 ± 0.2 kg•m
Retight-
en
Final value: 30 ± 1.0 kg•m
16
Tightening torque of upper
hinge retainer mounting
bolt.
When adjusting with shim: 8 ± 0.2 kg•m
Final value: 30 ± 1.0 kg•m
17 Tightening torque of upper
hinge pin mounting bolt.
13 ± 1.0 kg•m
18 Tightening torque of lower
hinge pin mounting bolt.
30 ± 1.0 kg•m
