Daewoo Mega 500-V - Torque Limits for Locking Screws (in Nm); Torque Limits for Locking Screws with Locked Toothing (in Nm)

S0602170K
Page 7
Axle (ZF AP 420R)
Torque Limits for Locking Screws (In Nm).
Torque Limits for Locking Screws with Locked Toothing (In Nm).
Metric ISO-Standard Thread
DIN 13, (See page 60)
Metric ISO-Fine Thread
DIN 13, (See page 60)
Size 10.8 12.9 Size 10.8 12.9
M 5
M 6
M 7
7.8
13.2
22.0
10.8
18.2
30.0
M 8 x 1
M 10 x 1
M 10 x 1, 25
34
68
65
47
94
89
M 8
M 10
M 12
32
61
108
44
84
148
M 12 x 1, 25
M 12 x 1, 5
M 14 x 1, 5
118
113
185
163
155
254
M 14
M 16
M 18
169
263
358
233
362
493
M 16 x 1, 5
M 18 x 1, 5
M 20 x 2
280
405
536
385
556
737
M 20 508 698
Metric ISO-Standard Thread
DIN 13, (See page 60)
Metric ISO-Fine Thread
DIN 13, (See page 60)
Size 12.9 Size 12.9
M 5
M 6
M 8
10.5
17.5
42.0
M 8 x 1
M 10 x 1, 25
M 10 x 1
46
86
91
M 10
M 12
M 14
81
140
225
M 12 x 1, 5
M 12 x 1, 25
M 14 x 1, 5
150
155
245
M 16
M 18
M 20
350
470
680
M 16 x 1, 5
M 18 x 2
M 18 x 1, 5
375
500
530
M 20 x 2
M 20 x 1, 5
710
750
