S0802190K
Page 3
Electrical System
Return to Master Table of Contents
OVERVIEW
The electrical system for this equipment is DC 24 volts. The rated voltage for all electric components is 24
volts with the exception of the car stereo and the air-conditioning control actuator. The system contains two
12 volt batteries connected in series and a three phase AC generator with a rectifier. The electric wiring
used in the system is easily identifiable by the insulator color. The color symbols used in the electric
system is listed in the following chart.
Electric Wire Color
NOTE:
RW: Red wire with White stripe
R - Base Color, W - Stripe Color
NOTE:
0.85G: Nominal sectional area of wire core less insulator = 0.85 mm
2
(0.03 in
2
)
Symbol Color
W White
G Green
Or Orange
B Black
L Blue
Lg Light Green
R Red
Gr Gray
P Pink
Y Yellow
Br Brown
V Violet
Symbol Color
