S0607080K
Page 6
Transmission and Torque Converter
(ZF 4WG-310)
TRANSMISSION AND TORQUE CONVERTER
The machine contains a powershift transmission that has four forward speeds and three speeds in
reverse. Gear changes are made by an elector-hydraulic control valve that is mounted on transmission.
Moving gear select lever in cab, generates an electrical signal that is transmitted to the control valve. The
control valve contains proportional valves that direct pressurized fluid to various clutches that control the
forward and reverse gears.
Item Mega 500-V
Torque Converter Model 4WG-310 (Full Auto)
Type 3-Element, 1-Stage, Single-phase,
E/G mounted with flexible plate
Oil Cooler Water-cooled (multiplate) and Air-cooled
Charging Pump 130
l
/min at 2,000 rpm
Hydraulic Pump P.T.O 1:1
T/C Size
∅
370 mm (14.5669 in)
Stall Ratio 2,985
Safety Relief 11 Bar (160 psi)
Transmission Type Full Power Shift, Counter shaft
Speeds 4 Forward / 3 Reverse
Ratio F: 3.73 / 2.206 / 1.969 / 0.624
R: 3.73 / 2.206 / 0.969
Power Shift Control
Pressure
16 - 18 Bar (232 - 261 psi)
Shift Control Electric Shift with Proportional Valve
Oil Capacity 50
l
(13.2 U.S. gal)
Dry Weight 750 kg (1,653 lb)
Output Flange Front 9C Mechanics
Rear 9C Mechanics
