Daewoo Mega 500-V - Refrigerant Circulation

S0605050K
Page 4
Air Conditioner
Return to Master Table of Contents
REFRIGERANT CIRCULATION
1
2
3
4
5
6
HBOI020L
7
Figure 3
Reference
Number
Description
1 Evaporator
2 Expansion Valve
3 Condenser
4 Condenser Fan
5 Compressor
6 Blower Fan
7 Receiver Dryer
Reference
Number
Description
