Daewoo Mega 500-V - Clutch Pack and Solenoid Valve Cross-Reference Table

S0607900C
Page 9
Transmission Error Codes (ZF)
CLUTCH PACK AND SOLENOID VALVE CROSS-
REFERENCE TABLE
Throughout the fault codes, references are made to various clutch packs within the transmission. These
clutch pack references are indicated as K1, K2, etc.
Clutch pack charge pressure is controlled by proportional valves that contain a solenoid valve.
The following chart identifies which solenoid valve corresponds to each clutch pack.
Clutch Pack
Solenoid Valve (Proportioning Valve) Number
Mega 130
4WG-100
Mega 160
4WG-130
Mega 250-V
4WG-190
Mega 300-V
4WG-210
Mega 400-III PLUS
4WG-260
Mega 400-V
4WG-260
Mega 500-V
4WG-310
K1 Y3 Y3 Y3 Y3 Y3 Y3 Y3
K2 Y6 Y6 Y6 Y6 Y6 Y6 Y6
K3 Y4 Y4 Y4 Y4 Y4 Y4 Y4
K4 Y1 Y1 Y1 Y1 Y2 Y2 Y2
KR Y2 Y2 Y2 Y2 Y1 Y1 Y1
KV Y5 Y5 Y5 Y5 Y5 Y5 Y5
