S0709665K
Page 5
Flow Amplifier (Danfoss)
SPECIFICATIONS
Reference
Number
Description
1 O-ring
2 O-ring
3 O-ring
4 O-ring
5 Washer
6 Washer
7 O-ring
8 O-ring
9 Housing
10 Check Valve
11 Screw
12 Washer; Spring
13 Screw
14 Washer; Spring
15 End Cover
16 End Cover
17 Relief Valve
20 Plug
21 Shock and Suction Valve
22 Stopper
23 Stopper
24 Guide; Spring
25 Screw; Drive
26 Plate; Name
27 Orifice
28 Spring
29 Spring
30 Spring
31 Plug
32 Washer
34 Orifice
35 Orifice
36 Orifice
37 Throttle Check Valve
38 Plug
40 Spring
41 Spring
Reference
Number
Description
Flow Amplifier Specification
Type Contains a directional valve, an amplification stage, a priority
valve, a pilot pressure relief valve and suction valve.
Amplification Factor 8
Control Pressure
10.50 kg/cm
2
(149.35 psi)
LS Relief Valve Setting 185.0 ±5.0 bar (2,683.24 ±72.52 psi))
Max. Oil Flow to Steering 125.0 l/min. (33.0 U.S. gpm)
