Daewoo Mega 500-V - Specifications

S0709240K
Page 8
Brake Pedal Valve
SPECIFICATIONS
Item Specifications
System Flow 41 l /min @ 37 bar
(10.8 gpm @ 535 psi)
Setting Pressure C1 37 ±2 kg/cm
2
@ 20 l /min
(526 ±28 psi @ 5.3 gpm)
Port Size T1 PF 1/2 O-ring
TP PF 1/4 O-ring
All other ports PF 3/8 O-ring
AHS3790L
Figure 5 HYDRAULIC CIRCUIT
