S0607080K
Page 42
Transmission and Torque Converter
(ZF 4WG-310)
FRONT VIEW
Figure 37
Reference
Number
Description
1 Lifting Lugs
2 Breather
3 Electro-hydraulic Shift Control
4 Diaphragms - Direct Mounting
5 Converter
6 Output Flange (Converter-side)
7 Coarse Filter
8 Oil Drain Plug
9 Attachment Possibility for Oil
Filter Tube with Oil Dipstick
(Converter-side)
10 Oil Filler Tube with Oil Dipstick
(Rear-side)
Reference
Number
Description
