Transmission Error Codes (ZF)
INTRODUCTION
The "WG" series of ZF Transmissions use an electronic control system called "ZF-Ergopower."
The Ergo System (for short) allows the transmission to function either in a manual powershift mode, or in a
fully automatic mode.
An LCD display (Figure 1) is in the cab. This display gives the machine operator a continuos status of the
operating condition of the system. It displays normal operational codes, and fault codes.
ABBREVIATIONS
Throughout this section the following abbreviations are used to indicate various conditions.
Abbreviations
ABS Anti Blocking System
ADM (1 - 8) ??????
AEB
??????
ASR Anti Slipping Regulation
CAN Controller Area Network
CCO Clutch Cut Off
DCO ??????
DCT1
??????
DNS1
??????
EAM1
??????
EAMODUL1
??????
EEC (1, 3) Electronic Engine Controller
FMR (1 and 2)
??????
LIS (1 and 2) Load Isolation System
(Solenoids 1 and 2)
MDU1
??????
O.C. Open Circuit
OMRON
??????
OP-Mode OPeration Mode
PTO Power Take Off
S.C. Short Circuit
SCT1
??????
TCU Transmission Control Unit
VPS (1 and 2) ??????
