Daewoo Mega 500-V - Air Discharge According to Path Selection

S0605050K
Page 9
Air Conditioner
Return to Master Table of Contents
AIR DISCHARGE ACCORDING TO PATH SELECTION
Vent
Figure 9
AJS0540L
Reference
Number
Description
1 Select Switch
2 Front Vent
2-1 Front Vent (R)
2-2 Front Vent (L)
3 Rear Vent
3-1 Rear Vent (R)
3-2 Rear Vent (L)
4 Heater Core
5 Evaporator Core
6 Air Filter
7 Blower Motor
Reference
Number
Description
