Daewoo Mega 500-V - Cleaning and Inspection (Wear Limits and Tolerances)

S0705010
Page 13
Cylinders
Return to Master Table of Contents
7. Use caution to prevent damage to any
parts of U-packing (1, Figure 13). Remove
U-packing (1). Remove O-ring (2), and ring
(3).
CLEANING AND INSPECTION (WEAR LIMITS AND
TOLERANCES)
For general cleaning and inspection procedures, refer to "General Maintenance Procedures" section.
Reference
Number
Description
1 U-Packing
2 O-Ring
3 Ring
Figure 13
