Daewoo Mega 500-V - Temperature Level Control and Display

S0605050K
Page 8
Air Conditioner
Return to Master Table of Contents
TEMPERATURE LEVEL CONTROL AND DISPLAY
Step LED 1 LED 2 LED 3 LED 4 LED 5 LED 6 LED 7
Position
Sensor
Voltage
Remark
0 Green Green Green Green Green Green Green 4.50 V ±0.2 MAX. COOL
1 Green Green Green Green Green Green Green 4.33 V ±0.2
2 Green Green Green Green Green Green Green 4.15 V ±0.2
3 Red Green Green Green Green Green Green 3.98 V ±0.2
4 Red Green Green Green Green Green Green 3.80 V ±0.2
5 Red Green Green Green Green Green Green 3.63 V ±0.2
6 Red Red Green Green Green Green Green 3.46 V ±0.2
7 Red Red Green Green Green Green Green 3.28 V ±0.2
8 Red Red Green Green Green Green Green 3.11 V ±0.2
9 Red Red Red Green Green Green Green 2.93 V ±0.2
10 Red Red Red Green Green Green Green 2.76 V ±0.2
11 Red Red Red Green Green Green Green 2.59 V ±0.2
12 Red Red Red Red Green Green Green 2.41 V ±0.2
13 Red Red Red Red Green Green Green 2.24 V ±0.2
14 Red Red Red Red Green Green Green 2.07 V ±0.2
15 Red Red Red Red Red Green Green 1.89 V ±0.2
16 Red Red Red Red Red Green Green 1.72 V ±0.2
17 Red Red Red Red Red Green Green 1.54 V ±0.2
18 Red Red Red Red Red Red Green 1.37 V ±0.2
19 Red Red Red Red Red Red Green 1.20 V ±0.2
20 Red Red Red Red Red Red Green 1.02 V ±0.2
21 Red Red Red Red Red Red Red 0.85 V ±0.2
22 Red Red Red Red Red Red Red 0.67 V ±0.2
23 Red Red Red Red Red Red Red 0.50 V ±0.2 MAX. HOT
