S0602170K
Page 19
Axle (ZF AP 420R)
Disassembly Reassembly Subject-No. Denomination /Application Special Tool (S)
Figure 18 5870 350 000 Assembly car compl. with tilting device
5870 350 008 Support
Figure 21 5870 970 004 Two-leg puller
Figure 24
Figure 134,
Figure 142
5870 900 010 Clamping pliers
Figure 27,
Figure 33
5870 400 001 Adjustment device
Figure 28
Figure 111,
Figure 125
5870 401 097 Hook spanner
5870 912 Ol2 Centering bracket
Figure 30,
Figure 35
5870 345 036 Pry bar (set of 2)
Figure 30 Figure 110 5870 281 033 Lifting bracket
Figure 31 5870 281 016 Expanding claw
Figure 32 Figure 123 5870 281 034 Spring hook
Figure 34 5870 028 007 Grab sleeve "super"
Figure 103 5870 204 044 Adjusting screw M20 x 1.5 (set of 2)
Figure 104 5870 610 001 Wheel stud puller - Basic set
5870 610 002 Insert M22 x 1.5
Figure 105 5870 050 004 Driver
5870 260 004 Driver
Figure 105 5870 050 011 Driver
5870 260 004 Driver
Figure 110,
Figure 115,
Figure 125
5870 651 049 Installer M110 x 1.5
Figure 112 5870 230 007 Spring scale O - 200 N
Figure 114 5870 051 023 Driver
5870 260 004 Driver
Figure 119 5870 651 042 Installer
∅
260 mm (10.2362 in)
5870 651 043 Installer
∅
315 mm (12.4016 in)
Figure 121 5870 654 Ol8 Clamping plate
5870 970 006 Two-leg puller
Figure 150 5870 287 007 HP-Pump
