Daewoo Mega 500-V - Page 126

S0602170K
Page 21
Axle (ZF AP 420R)
Disassembly Reassembly Subject-No. Denomination /Application Special Tool (S)
Figure 18 5870 350 000 Assembly car compl. with tilting device
5870 350 053 Support
Figure 21 5870 080 030 Cross bracket
5870 027 032 Cover and spindle
5870 080 031 Puller hook # 2 pieces needed
Figure 24
Figure 134,
Figure 142
5870 900 024 Clamping pliers
Figure 27 5870 400 001 Adjustment device 2 Pieces needed
Figure 28
Figure 111,
Figure 125
5870 401 098 Hook spanner
5870 912 012 Centering bracket
Figure 28 Figure 111 5870 401 106 Hook spanner
5870 912 012 Centering bracket
Figure 28 Figure 111 5870 401 097 Hook spanner AP 417
Figure 30,
Figure 35
5870 345 036 Pry bar (set of 2)
Figure 30 Figure 110 5870 281 033 Lifting bracket
Figure 31 5870 281 016 Expanding claw
Figure 32 Figure 123 5870 281 034 Spring hook
Figure 34 5870 028 008 Grab sleeve "super"
Figure 34 5870 028 011 Grab sleeve "super"
Figure 103 5870 204 045 Adjusting screw M24 (set of 2)
Figure 104 5870 610 001 Wheel stud puller - Basic set
5870 610 002 Basic set M22 x 1.5
Figure 105 5870 050 011 Driver
5870 260 004 Driver
Figure 110,
Figure 115,
Figure 125
5870 651 041 Installer M130 x 1.5
Figure 110,
Figure 115,
Figure 125
5870 651 049 Installer M110 x 1.5
Figure 112 5870 230 007 Spring scale O - 200 N
Figure 114 5870 051 023 Driver
5870 260 004 Driver
Figure 119 5870 651 042 Installer ∅ 260 mm (10.2362 in)
5870 651 043 Installer ∅ 315 mm (12.4016 in)
Figure 121 5870 654 018 Clamping plate
5870 970 006 Two-leg puller
Figure 150 5870 287 007 HP-Pump
