S0602170K
Page 23
Axle (ZF AP 420R)
Disassembly Reassembly Subject-No. Denomination /Application Special Tool (S)
Figure 39 5870 240 016 Back-off screws M18 (set of 2)
Figure 41 5870 900 010 Clamping pliers
Figure 42 Figure 194 5870 204 022 Adjusting screws M14 (set of 2)
Figure 43 5870 350 000 Assembly car compl. with tilting device
5870 350 004 Support
5870 350 005 Insert "BK/CK"
Figure 44 5870 345 036 Pry bar (set of 2)
Figure 47 5870 026 001 Grab sleeve "Super"
5870 506 058 Pressure piece
5870 026 100 Back-off insert
Figure 47 5870 027 025 Grab sleeve "Super"
5870 506 058 Pressure piece
5870 027 000 Basic set
Figure 53
Figure 164,
Figure 166,
Figure 169
5870 240 025 Clamping yoke
Figure 58 5870 027 004 Grab sleeve "Super"
Figure 154 5870 500 001 Measuring shaft
5870 500 028 Adjusting piece
5870 351 016 Measuring pin
5870 351 010 Stop washer
5870 351 011 Spacer
Figure 168 5870 048 118 Driver
Figure 187 5870 200 055 Magnetic base
Figure 189 5870 200 057 Dial indicator
Figure 192 5870 900 023 Wire pincers
