S0602170K
Page 29
Axle (ZF AP 420R)
Disassembly Reassembly Subject-No. Denomination /Application Special Tool (S)
Figure 60 5870 204 016 Back-off screws M18 (set of 2)
Figure 63 5870 900 010 Clamping pliers
Figure 64 5870 204 012 Back-off screws M12 (set of 2)
Figure 64 5870 350 000 Assembly car compl. with tilting device
5870 350 006 Support
Figure 69 5870 027 029 Grab sleeve "Super" 33 281
Figure 69 5870 027 030 Grab sleeve "Super" JM 714 249
5870 027 000 Basic set
Figure 70 5870 345 036 Pry bar (set of 2)
Figure 76 Figure 208,
Figure 212
5870 240 025
Clamping yoke
Figure 81 5870 027 021 Grab sleeve "Super" 31 313
Figure 198 5870 500 001 Measuring shaft
5870 500 006 Adjusting piece (set of 2)
5870 351 016 Measuring pin
5870 351 013 Stop washer
Figure 202 5870 058 060 Drive
Figure 204 5870 340 001 Measuring ring
Figure 211 5870 048 118 Driver
Figure 234 5870 200 055 Magnetic base
Figure 235 5870 200 057 Dial indicator
Figure 239 5870 057 025 Driver
Figure 240 5870 204 021 Adjusting screws M14 (set of 2)
5870 260 002 Handle
